Bed Sheet and Duvet Cover Automatic Folding Machine

Automatic folding equipment for large flat linen, helping hotel laundries and commercial plants improve finishing speed after ironing.

Request Quote

Bed sheet and duvet cover automatic folding machine side view

Automatic folding machine rear and outlet view

Product overview

The ZD series automatic folding machine is designed for bed sheets, duvet covers, and other large flat linen after ironing or finishing. It helps reduce manual folding labor, stabilize folding size, and improve output consistency in hotel laundry rooms, hospital laundry plants, and commercial linen service operations.

Key features

Designed for large flat linen such as bed sheets, duvet covers, and similar hospitality textiles.
Supports continuous finishing workflow after flatwork ironing.
ZD3000-V and ZD3300-V options for different linen width requirements.
Suitable for hotel laundries, central laundry plants, hospitals, and linen rental operations.
Helps reduce manual folding work and improve presentation consistency.

ZD series specifications

Model	ZD3000-V	ZD3300-V
Maximum folding length x width	3600 x 3000mm	3600 x 3300mm
Working capacity	30m/min for common bed sheets	30m/min for common bed sheets
Air source pressure	0.5-0.7MPa	0.5-0.7MPa
Rated input power	1.1 + 0.75 + 0.4kW	1.1 + 0.75 + 0.4kW
Power consumption	0.6kW/h	0.6kW/h
Air compressor exhaust volume	0.3m3/min	0.3m3/min
Overall dimensions	4640 x 2530 x 1930mm	4940 x 2530 x 1930mm
Machine weight	1450kg	1500kg
Power supply	380V / 3-phase / 50Hz	380V / 3-phase / 50Hz

Specification guidance

Function	Automatic folding for bed sheets, duvet covers, and large flat linen
Best paired with	Flatwork ironer, washer extractor, and tumble dryer
Buyer focus	Linen width, folding speed, air source, floor space, and finishing line layout
Recommended inquiry data	Linen size, daily sets, existing ironer width, voltage, and workshop layout
